ACOUSTIC SIGNATURE MCX-1
Brand
Acoustic Signature
SKU
MCX-1
630,00 €
Κεφαλή κινητού πηνίου ελειπτικού τύπου.
Σημείωση:
Κεφαλή κινητου πηνίου ACOUSTIC SIGNATURE MCX-1
Calculating...
Λεπτομέρειες προϊόντος:
- Modern MC cartridge with copper coils
- Resonance-optimized aluminum chassis
- Easy mounting
- Precise tracking due to elliptical stylus
- Suitable for medium to high mass tonearms
Προδιαγραφές:
| Characteristic | Feature |
|---|---|
| Cartridge system: | Moving-coil |
| Stylus type: | Elliptical |
| Coil material: | Copper |
| Cartridge chassis: | Resonance-optimized aluminum chassis |
| Voltage output (at 1 kHz, 5 cm/sec.): |
0.55 mV |
| Channel balance at 1 kHz: | < 1.5 dB |
| Channel separation at 1 kHz: | > 21 dB |
| Compliance, dynamic, lateral: | 15 m/mN |
| Tracking force range: | 2.1 to 2.5 g |
| Recommended tracking force: | 2.3 g (23 mN) |
| Frequency range at -3 dB: | 20-25,000 Hz |
| Frequency response 20-20,000 Hz: | ± 2.5 dB |
| DC resistance: | 7 |
| Recommended load: | 100 |
| Cartidge weight: | 12.2 g |
| Σημείωση: | Κεφαλή κινητου πηνίου ACOUSTIC SIGNATURE MCX-1 |
|---|---|
| Cartridge Type: | MC |
| Output voltage at 1000 Hz, 5cm/sec | 0.55 mV |
| Tracking force, recommended: | 2.3 g (23 mN) |
| Tracking force range: | 2.1 to 2.5 g |
| Recommended load resistance: | 100 |
| Frequency range at - 3dB: | 20-25,000 Hz |
| Frequency response: | ± 2.5 dB |
