Clearaudio Basic v2 silver

Mode MM/MC (Subsonic filter switchable) Amplification @ 1 kHz +46 dB (MM mode)
+66 dB (MC mode) Input impedance 47 kOhm / 270 pF / MM mode
500 Ohm / 270 pF / MC mode MM / MC input switchable (at bottom) RIAA 75 μs / 318 μs / 3180 μs, 2 passive filter RIAA accuracy ± 0.10 dB THD < 0.002% (IEC A) Signal to noise ratio -72 db (MM mode)
-67 dB (MC mode) Channel separation > 90 dB (@ 1 kHz) Max. output voltage >10 V (@ 1 kHz) Subsonic filter 20 Hz (–18 dB / Oct.; switchable on bottom panel, on each channel) Power consumption Max. consumption in operation: 3 watts
Standby mode: <0.3 watts Power supply ± 18 V DC (external power supply, 1.4m cable length) Output connections Unbalanced (RCA) Total weight Approx. 1.2 kg (Preamp and power supply) Dimensions (W/D/H in inches) Preamp: 4.64 x 5.71 (6.22 with RCA) x 1.65
Power Supply: 3.94 x 2.17 x 3.46 Dimensions (W/D/H in mm) Preamp: 118 x 145 (158 with RCA) x 42
Power Supply: 100 x 55 x 80 Warranty 3 years*
* Provided the warranty card is fully completed and returned to Clearaudio within 2 weeks of purchase.
