Clearaudio master innovation black piano wood

Construction principle

• Resonance–optimised chassis shape
• Made of bullet proof wood and aluminium with precision CNC machined surface
• All turntable feet are fine adjustable
• Optical Speed Control (OSC)
• Playback with three tonearms possible

Speed rangesComfortable speed change
33 ⅓, 45 and 78 rpmDrive unit

• High torque DC motor exclusively made for Clearaudio; Optical Speed Control (OSC) in real time through infrared sensor
• Decoupled DC motor in chassis; resonance damping device; belt-driven
• Magnetic decoupling of turntable and addtional drive platter

Bearing

• Clearaudio patented ceramic magnetic bearing (CMB) in main platter / upper drive platter assembly
• Inverted bearing in lower drive platter

Platter70 mm (2.75 inch) main platter, made out of synthetic material with high density and excellent dimension stability, precision CNC machined surface, solid stainless steel subplatter, dynamically balanced
15 mm (4/5 inch) precision CNC machined dynamically balanced stainless steel sub–platterSpeed variation< ± 0.05 %

Power consumptionMax. consumption: 9.5 Watt
Consumption in operation: 4.1 Watt
Standby mode: 2.4 Watt
Off mode: 0.0 WattTotal weightApprox. 60 kg (without tonearm and power supply)Dimensions (W/D/H in inches)Approx. 18.11 x 19.09 x 15.59 (with tonearmbase, without tonearm)Dimensions (W/D/H in mm)Approx. 460 x 485 x 396 (with tonearmbase, without tonearm)Warranty5 years*
* Provided the warranty card is fully completed and returned to Clearaudio within 2 weeks of purchase.
