GigaWatt G-044 Duplex SCHUKO Wall Socket

Το G-044 SCHUKO DUPLEX είναι μια υψηλής ποιότητας, διπλή πρίζα στον τοίχο, σχεδιασμένη για χρήση σε οικιακά ηλεκτρικά δίκτυα που τροφοδοτούν συστήματα ήχου-βίντεο.

G-044 SCHUKO DUPLEX is a high quality, double, in-wall power socket, designed to be used in home electrical grids powering audio-video systems.

The solid connectors of the socket are made from brass, and their surface is protected against oxidation. Powerful contact and large connection surface of the connectors with a width of 10mm guarantee perfect connection with the plug pins. Additionally the connectors were de-magnetized. As a standard, the sockets are equipped with bolted connectors allowing the usage of large diameter cables. The construction of the socket has a mounting depth of less than 30mm. Wall mount is possible using strong expansion feet or bolts.

The internal chassis is made by Merten Schneider, from hard to break, high quality, matte plastic and has a grey finish. The faceplate is made from solid, anodized aluminum, 6mm thickness. G-044 SCHUKO DUPLEX can be mounted horizontally or vertically.

NOTE: Installation works exposes to direct contact with potentially lethal voltage. There is risk of an electric shock! All activities related to installation can only be made by a qualified personnel following appropriate regulations (DIN VDE 0100 and IEC 664 or DIN VDE 0110).

Line voltage: 110-250 VAC / 50-60 Hz
Maximum current load: 16 A
Dimensions: 95 x 166 x 35,5 mm
Gross Weight: 0,43 kg
