LYRA ETNA λ

 Κεφαλή κινητού πηνίου σχεδιασμένη απο τον σχεδιαστή Jonathan Carr

Specifications for Lyra Etna λ Lambda

• Type: Medium weight, medium compliance, low-impedance moving coil cartridge
• Stylus: Lyra-designed long-footprint variable-radius line-contact nude diamond (3μm×70μm), slot-mounted
• Cantilever system: Diamond-coated solid boron rod with short one-point wire suspension, directly mounted into cartridge body via high-pressure knife-edge system
• Body: Machined titanium central core, anodized aluminum
• Coils: 2-layer deep, 6 N high-purity copper, chemically-purified high-purity iron cross-shaped former, 4.2 ohm self-impedance, 11μH inductance
• Output voltage: 0.56 mV@5 cm/sec., zero to peak, 45 degrees (CBS test record, other test records may alter results)
• Frequency range: 10 Hz~50 kHz
• Channel separation: Greater than 30dB at 1kHz
• Compliance: Approx. 12×10 cm/dyne at 100 Hz
• Cartridge mounting screws: 2.6 mm 0.45 pitch JIS standard
• Cartridge weight (without stylus cover): 9.2g
• Distance from mounting holes to stylus tip: 9.5 mm
• Recommended tracking force: 1.62 - 1.72g
• Recommended load directly into MC phono input: Detailed guidelines in instruction manual, finalize by listening
• Recommended load via step-up transformer: Use a step-up transformer designed for 3 -6 ohms cartridge impedance (step-up transformer’s output must be connected to 10kohm ~ 47kohm MM-level RIAA input, preferably via short, low-capacitance cable)
• Recommended tonearms: Medium to Medium-High mass arms recommended, which is bulk of tonearm market

Specifications for Lyra Etna λ Lambda SL

• Designer: Jonathan Carr
• Builder: Yoshinori Mishima
• Type: Medium weight, medium compliance, low-impedance moving coil cartridge
• Stylus: Lyra-designed long-footprint variable-radius line-contact nude diamond (3μm× 70μm), slot-mounted
• Cantilever system: Diamond-coated solid boron rod with short one-point wire suspension, directly mounted into cartridge body via high-pressure knife-edge system
• Body: Machined titanium central core, anodized aluminum
• Coils: Single layer, 6 N high-purity copper, chemically-purified high purity iron cross-shaped former, 1.52 ohm self impedance, 1.9μH inductance
• Output voltage: 0.25mV@5 cm/sec., zero to peak, 45 degrees (CBS test record, other test records may alter results)
• Frequency range: 10 Hz〜50 kHz
• Channel separation: Greater than 30dB at 1kHz
• Compliance: Approx. 12× 10 cm/dyne at 100 Hz
• Cartridge body: Multi-material (titanium, duralumin, bronze, stainless steel) self-clamping construction with reduced-surface higher-pressure headshell contact area, predominately non-parallel shaping, phase-interference resonance-controlling mechanisms, and body threaded directly for mounting screws
• Cartridge mounting screws: 2.6 mm 0.45 pitch JIS standard
• Cartridge weight (without stylus cover): 9.2g
• Distance from mounting holes to stylus tip: 9.52mm
• Recommended tracking force: 1.62 - 1.72g
• Recommended load directly into MC phono input: Detailed guidelines in instruction manual, finalize by listening.
• Recommended load via step-up transformer: Use a step-up transformer designed for 1 - 3 ohms cartridge impedance (step-up transformer’s output must be connected to 10kohm ~ 47kohm MM-level RIAA input, preferably via short, low-capacitance cable)
• Recommended tonearm: Medium to Medium-High mass arms recommended, which is bulk of tonearm market

Specifications for Lyra Etna λ Lambda Mono

• Designer: Jonathan Carr
• Builder: Yoshinori Mishima (final build, testing), Akiko Ishiyama (preliminary build)
• Type: Medium weight, medium compliance, low-impedance, low-output moving coil cartridge
• Stylus: Lyra-designed long-footprint variable-radius line-contact nude diamond (3um x 70um profile, block dimensions 0.08 x 0.12 x 0.5mm), slot-mounted
• Cantilever system: Diamond-coated solid boron rod with short one-point wire suspension, directly mounted into cartridge body via high-pressure knife-edge system
• Body: Machined titanium central core, anodized aluminum
• Coils: Two individually isolated monophonic/monaural 6N high-purity copper coils wound in parallel (on top of each other) on a square-shaped chemically-purified high-purity iron former with 3.0 ohms self-impedance
• Output voltage: 0.56 mV@5 cm/sec., zero to peak, 45 degrees (CBS test record, other test records may alter results)
• Frequency range: 10 Hz〜50 kHz
• Channel separation: 35 dB or better at 1 kHz
• Compliance: Approx. 12×10 cm/dyne at 100 Hz
• Cartridge body: Multi-material (titanium, duralumin, bronze, stainless steel) self-clamping construction with reduced-surface higher-pressure headshell contact area, predominately non-parallel shaping, phase-interference resonance-controlling mechanisms, body threaded for mounting screws
• Cartridge mounting screws: 2.6 mm 0.45 pitch JIS standard
• Cartridge weight (without stylus cover): 9.2g
• Distance from mounting holes to stylus tip: 9.5mm
• Recommended tracking force: 1.62 - 1.72g
• Recommended load directly into MC phono input: Detailed guidelines in instruction manual, finalize by listening
• Recommended load via step-up transformer: Use a step-up transformer designed for 1 - 3 ohms cartridge impedance (step-up transformer’s output must be connected to 10kohm ~ 47kohm MM-level RIAA input, preferably via short, low-capacitance cable)
• Recommended tonearm: Medium to Medium-High mass arms recommended, which is bulk of tonearm market
