Ortofon MC Windfeld Ti
Brand
Ortofon
Κεφαλή κινητού πηνίου phono στην απόλυτη high-end κατηγορία
Calculating...
ΠΡΟΔΙΑΓΡΑΦΕΣ
Output voltage at 1000 Hz, 5cm/sec. - 0.2 mV
Channel balance at 1 kHz - 0.5 dB
Channel separation at 1 kHz - 25 dB
Channel separation at 15 kHz - 20 dB
Frequency range at - 3dB - 10 Hz - 50 kHz
Frequency response - 20 Hz - 20 kHz +2 dB/- 1 dB
Tracking ability at 315Hz at recommended tracking force - 90 µm
Compliance, dynamic, lateral - 13 µm/mN
Stylus type - Special polished Nude Ortofon Replicant 100 on Boron Cantilever
Stylus tip radius - r/R 5/100 µm
Tracking force range - 2.0-2.5 g (20-25 mN)
Tracking force, recommended - 2.3 g (23 mN)
Tracking angle - 23°
Internal impedance, DC resistance - 7 Ohm
Recommended load impedance - > 10 Ohm
Coil wire material - Aucurum
Cartridge body material - SLM Titanium and Stainless Steel
Cartridge colour - Titanium/Black
Cartridge weight - 11 g
| MPN | 5705796235135 |
|---|---|
| Cartridge Type: | MC |
| Output voltage at 1000 Hz, 5cm/sec | 0.2 mV |
| Tracking force, recommended: | 2.3 g (23 mN) |
| Tracking force range: | 2.0 – 2.5 g (20 – 25 mN) |
| Recommended load resistance: | 10 Ohm |
| Frequency range at - 3dB: | 10 Hz – 50 kHz |
| Frequency response: | 20 Hz – 20 kHz +2 / -1 |
