Naim NVC TT
Brand
Naim
Αξιοποιήστε στο έπακρο το βινύλιο σας με το NVC TT. Πολύ εύκολο στη χρήση, είναι απόλυτα συμβατό με οποιοδήποτε πικάπ με κεφαλές MC και MM και συνδέεται εύκολα με τους προενισχυτές NAC 332 ή NSC 222. Όταν συνδέεται με το αποκλειστικό τροφοδοτικό NPX TT, προσφέρει ακόμη πιο υψηλή απόδοση.
Calculating...
Αξιοποιήστε στο έπακρο το βινύλιο σας με το NVC TT. Πολύ εύκολο στη χρήση, είναι απόλυτα συμβατό με οποιοδήποτε πικάπ με κεφαλές MC και MM και συνδέεται εύκολα με τους προενισχυτές NAC 332 ή NSC 222. Όταν συνδέεται με το αποκλειστικό τροφοδοτικό NPX TT, προσφέρει ακόμη πιο υψηλή απόδοση.
Naim know-how
Under the leadership of our Technical Director, our engineers have developed specific electronic circuits to give the New Classic products superior performance. The best audiophile components have been chosen for NVC TT and highly precise measurements to achieve an uncompromising result. It is an innovative concept, which partly uses the association between the phono stage and the power supply like in Naim’s Solstice Special Edition.
Perfect integration in a complete system
NVC TT connects easily to preamplifiers NSC 222 and NAC 332 from the New Classic range. It has a dedicated power supply, NPX TT, for the ultimate vinyl listening experience.
A timeless design
Naim products are designed to be both contemporary and timeless. Our creations forgo any unnecessary adornments that would detract from the performance and sound quality delivered. The design of NVT TT is inspired by previous Naim creations, such as the SuperLine, but also the Statement amplifier. It is razor sharp, combining a sleek design, premium materials and adjustable logo brightness.
The story of Naim and aluminium
Our founder, Julian Vereker, immediately understood the many benefits of aluminium for wrapping Naim electronic components. He knew that delicate audio components are very sensitive to the effects of magnetic fields, thermal instability, unwanted vibrations, etc.
Χαρακτηριστικά
- Product Type Switchable MM/MC phono stage with MC load adjustment
Audio Outputs
- Max output signal: 8 Vrms
- Headroom:
- MM: 22dB ref 5mV input
- MC (low & high gain): 23dB ref 0.5mV input low gain setting, 17dB ref 0.5mV high gain setting
- Audio Inputs MM: (Partial) – 2dB at 20Hz and -3dB at 14Hz
- Audio Inputs Power Amp In+/-18V DC @300mA
- Audio Outputs Powered Accessory SocketsStereo RCA
- Crosstalk MM: >75dB
- THD + NMM: <0.005% ref 50mV input
- MC (low & high gain): <0.005% ref 1.5mV inpu
- Signal-to-Noise Ratio MM: 83dB réf. 5 mV A-wtd
- MC (low & high gain): 84dB ref 0.5mV A-wtd (both gain settings)
- Gain MM: 42dB
- MC (low & high gain): 61dB low gain and 67dB high gain (switchable)
- Phono Specific RIAA Accuracy MM: +/-0.1dB
- Physical Weight7.5lbs (3.4kg)
- Dimensions (HxWxD)23/4x 83/8x 121/2" (7x21.4x31.7cm)
- Power Amplifier Output1 x Stereo RCA : 1 x 5 pin DIN, 1 x 8 pin DIN
Power Output
- MM: 47kΩ and 100pF
- MC (low & high gain):
- 16 selectable resistive values:
- 1 000 Ω, 600 Ω, 430 Ω, 330 Ω, 250 Ω,
- 215 Ω, 185 Ω,165 Ω,150 Ω, 140 Ω, 125 Ω,
- 115 Ω, 105 Ω, 100 Ω, 90 Ω, 85 Ω
- 16 selectable capacitive values:
- 100 pF, 400 pF, 700 pF, 1000 pF,
- 1300 pF, 1600 pF, 1900 pF, 2200 pF,
- 2500 pF, 2700 pF, 3100 pF, 3400 pF,
- 3700 pF, 4000 pF, 4300 pF, 4600 pF
- UpgradesPower SupplyType 1
