Ortofon 2M Red verso

ΠΡΟΔΙΑΓΡΑΦΕΣ

• Output voltage at 1000 Hz, 5cm/sec. 5,5 mV
• Channel balance at 1 kHz 1,5 dB - Channel separation at 1 kHz 22 dB Channel separation at 15 kHz 15 dB
• Frequency range at - 3dB 20-22.000 Hz - Frequency response 20-20.000 Hz + 3 / - 1 dB
• Tracking ability at 315Hz at recommended tracking force 70 µm
• Compliance, dynamic, lateral 20 µm/mN
• Stylus type Elliptical - Stylus tip radius r/R 8/18 µm
• Tracking force range 1,6-2,0g (16-20 mN) - Tracking force, recommended 1,8 g (18 mN) - Tracking angle 20°
• Internal impedance, DC resistance 1,3 kOhm - Internal inductance 700 mH
• Recommended load resistance 47 kOhm - Recommended load capacitance 150-300 pF
• Cartridge colour, body/stylus Black/Red - Cartridge weight 7,2 g
• Replacement stylus unit 2M Red

2M Red features: - an improved engine, which provides an increased output of 5.5mV and an optimized sound reproduction and a high level of sonic accuracy - a tipped Elliptical diamond and split pole pins with a copper wire 2M Red is an all-purpose cartridge that delivers open, dynamic sound with a slight touch of warmth. The 2M Red Verso model is an alternative product for bottom mount tonearms.
