Τεχνικές προδιαγραφές
Output voltage at 1000 Hz, 5cm/sec. - 3,3 mV
Channel balance at 1 kHz - < 2 dB
Channel separation at 1 kHz - > 22 dB
Channel separation at 15 kHz - > 15 dB
Frequency range at - 3dB - 20-25.000 Hz
Frequency response - 20-20.000 Hz + 4 / - 1 dB
Tracking ability at 315Hz at recommended tracking force *) - > 65 µm
Compliance, dynamic, lateral - 13 µm/mN
Stylus type - Elliptical
Stylus tip radius - r/R 8/18 µm
*) Typical value
Tracking force range - 1,8-2,2 g (18-22 mN)
Tracking force, recommended - 2 g (20 mN)
Tracking angle - 20°
Internal impedance, DC resistance - 100 Ohm
Recommended load impedance - 47 kOhm / < 500 pF
Cartridge body material - Noryl
Cartridge colour - Black
Cartridge weight - 4,1 g
Features and applications
The MC-1 Turbo is an excellent entry into the world of high output Moving Coil (MC) cartridges, with an elliptical stylus profile.
The MC-1 Turbo has a 3.3mV output, which makes it perfect for use with inbuilt phono preamps – specifically ones designed for Moving Magnet (MM) cartridges.
The MC-1 Turbo provides a taste of the linearity and precision of moving coils, but without the need for additional high gain preamps or transformers.
Cartridge Type: | MC |
---|---|
Output voltage at 1000 Hz, 5cm/sec | 3,3 mV |
Tracking force, recommended: | 2 g (20 mN) |
Tracking force range: | 1,8-2,2 g (18-22 mN) |
Recommended load resistance: | 47 kOhm |
Recommended load capacitance: | / < 500 pF |
Frequency range at - 3dB: | 20-25.000 Hz |
Frequency response: | 20-20.000 Hz + 4 / - 1 dB |
