ORTOFON MC VERISMO
Brand
OrtofonΗ MC Verismo έχει αναπτυχθεί με βάση την εκτεταμένη γνώση μας σχετικά με τις ιδιότητες των κραδασμών, τα διαφορετικά σχήματα και τα χαρακτηριστικά των υλικών, καθώς και τις ικανότητες στον μαγνητισμό, τη μηχανική σχεδίαση και τις τεχνολογίες. Η MC Verismo προσφέρει αναμφίβολα ήχο που απλά πρέπει να βιώσετε.
Calculating...
Η MC Verismo έχει αναπτυχθεί με βάση την εκτεταμένη γνώση μας σχετικά με τις ιδιότητες των κραδασμών, τα διαφορετικά σχήματα και τα χαρακτηριστικά των υλικών, καθώς και τις ικανότητες στον μαγνητισμό, τη μηχανική σχεδίαση και τις τεχνολογίες. Η MC Verismo προσφέρει αναμφίβολα ήχο που απλά πρέπει να βιώσετε.
Design elements and high-end materials
The housing of the Verismo cartridge is made in Titanium with the Selective Laser Melting (SLM) technique pioneered by Ortofon. This technique allows for precise control of the density of the body material, allowing for extremely high internal damping.
The MC Verismo makes use of Ortofon’s Replicant 100 diamond. This Line Contact type stylus distinguishes itself by having a narrow and long contact surface, which is as close as possible to the original cutting stylus. This ensures the most accurate reproduction, lowest distortion and extended frequency range.
The addition of a solid Diamond cantilever provides the best possible interface between the stylus and armature, owing to its hardness and crystal structure. The improvements found in the use of a Diamond cantilever have redefined the boundaries of analogue reproduction, presenting greater inner detail, subtlety, and depth like never before.
Performance with a range of compatibility
In the MC Verismo the cartridge’s contact with the tonearm takes place through three well-defined contact points placed on the top side of the cartridge. This means that the mechanical integration of the cartridge and the tonearm arm is always absolutely perfect and will result in a significant and breathtaking increase in dynamics, resolution, and richness in detail.
With optimized weight and moderate compliance to suit the majority of modern tonearms, the MC Verismo is easily compatible with an endless array of contemporary high-end turntable equipment.
Technical data
Output voltage at 1 kHz, 5cm/sec. 0.2 mV
Channel balance at 1 kHz 0.5 dB
Channel separation at 1 kHz 25 dB
Channel separation at 15 kHz 20 dB
Frequency response 20 Hz-20 kHz +2 dB/- 1 dB
Tracking ability at 315 Hz at recommended tracking force 80 µm
Compliance, dynamic, lateral 13 µm/mN
Stylus type Special polished Nude Ortofon Replicant 100 on Diamond Cantilever
Stylus tip radius r/R 5/100 µm
Tracking force range 2.5-2.8 g (25-28 mN)
Tracking force, recommended 2.6 g (26 mN)
Tracking angle 23°
Internal impedance, DC resistance 7 Ohm
Recommended load impedance > 10 Ohm
Coil wire material Aucurum, gold-plated, 6NX oxygen free copper
Cartridge body material SLM Titanium
Cartridge colour Silver
Cartidge weight 9.5 g
