Ortofon stylus Nightclub MKII

Προδιαγραφές

• Output voltage at 1000Hz, 5cm/sec: 8 mV
• Channel balance at 1kHz: 1,5 dB
• Channel separation at 1kHz: 23 dB
• Channel separation at 15 kHz: 15 dB
• Frequency range at -3dB: 20-22.000
• Frequency response: 20-20.000 Hz +/- 1,5 dB
• Tracking ability at 315 Hz at recommmende tracking force: 80 μm
• Compliance, dynamic lateral: 7 μm/m N
• Stylus type: Special Elliptical
• Stylus tip radius: r/R 13/25 μm
• Tracking force range: 2,0-5,0 g (20-50 mN)
• Tracking force recommended: 3,0 g (30 mN)
• Tracking angle: 20°
• Internal impedance, DC resistance: 1.000 Ohm - Internal inductance: 580 mH
• Recommended load resistance: 47 kOhm - Recommended load capacitance: 200-600 pF
• Cartridge weight: 5 g
• Replacement stylus unit: Nightclub E MKII
