Rega Elex MK4
Brand
Rega
Calculating...
Ο Elex MK4 είναι ένας στερεοφωνικός ενισχυτής υψηλής απόδοσης που έχει σχεδιαστεί για να προσφέρει την πιο αγνή μουσική απόδοση. Τοποθετημένο σε νέο σασί για να ταιριάζει με την υπόλοιπη σειρά Rega, το MK4 βασίζεται σε προηγούμενα σχέδια Rega χρησιμοποιώντας το πολυβραβευμένο κύκλωμα ενισχυτή ισχύος A/B κατηγορίας που αποδίδει εντυπωσιακά 72W ανά κανάλι σε φορτία 8Ω (90W σε 6Ω) . Νέες επιλογές συνδεσιμότητας στο πίσω μέρος είναι διαθέσιμες με το Elex MK4 τώρα να περιλαμβάνει ένα κύκλωμα Rega DAC με δύο ψηφιακές εισόδους και μια έξοδο ακουστικών υψηλής ποιότητας που βρίσκεται σε βολική τοποθεσία στον μπροστινό μέρος.
Bringing your music to life
The Elex MK4 is capable of driving difficult loudspeakers with ease and will integrate perfectly into any audio system by offering a wider range of connectivity options. In addition to the line level, digital inputs and a high quality moving magnet phono stage, you will also find Pre-out and Record Out functionality alongside a headphone output. Special attention has been paid to the selection of key audio components. Discrete circuitry, high quality relays, polypropylene capacitors and Sanken output transistors are used throughout the design.
- 72 W per channel into 8 Ω / 90 W into 6 Ω
- High quality moving magnet phono stage
- High performance Rega DAC circuit for digital inputs
- 2 x Digital inputs - 1 x optical and 1 x Co-Axial
- Headphone output
- 4 Line level inputs
- New custom design case
- Thermal Cut-Out
Product Details
- Amplification circuit
Our engineers have re-engineered the entire ELEX circuit board to optimise performance. MK4 builds on previous Rega designs by using our multi-award-winning Class A/B power amplifier circuit to deliver a powerful 72W per channel into 8Ω loads. This power is provided by a quiet multi-stage linear supply whilst supply rails for digital and analogue sections are galvanically isolated.
- Digital Circuit / DAC
The DAC is based closely on the hugely successful Rega DAC-R circuit. The galvanically/optically isolated digital inputs utilise a Wolfson S/PDIF receiver IC to provide exceptional detail and clarity from any connected source. Output is provided by a Wolfson DAC and Rega designed discrete line-driver circuit. Our engineers have worked exceptionally hard to ensure that the analogue side of the circuit is not affected in any way by the introduction of digital inputs.
A high performance Rega designed integrated moving magnet (MM) phono stage is carefully built into the circuit. The RIAA equalization has been split into two stages to minimise interaction. Polyester capacitors have been used in the signal path and polypropylene capacitors are used in the RIAA equalization circuits.
We have taken great care to incorporate the headphone socket on the Elex MK4. This has been configured such that the speaker switching is performed by the output mute relay to avoid obstructing the signal path ensuring no loss of performance when it is not in use.
The new custom case design and construction brings the Elex MK4 inline with the rest of the Rega range and provides improved heat dissipation by using the entire case as an ultra efficient heat sink.
The Elex MK4 includes Thermal Cut-Out, short circuit protection and DC protection to prevent the risk of damage from excess heat, excessive currents or short circuits.
Technical Specifications
- Power Amplifier Output (at rated 230/115 V Supply voltage)
-
72 W into 8 Ω
90 W into 6 Ω - Dimensions (W × H × D)
-
432 x 82 x 340 (D includes loudspeaker terminals)
- Weight
-
11 Kg
- Supported Sampling Rates
-
32, 44.1, 48, 88.2, 96, 176.4, 192kHz
- Supported Bit Depths
-
16 to 24 bit
- Power Consumption
-
250 W at 1dB below clip into 8Ω
- Output Sensitivity (at rated inputs)
-
Record Output 164mV
Pre-amplifier Output 625mV
-
- Digital Circuit / DAC
| MPN | 5056 18670 7603 |
|---|
