Χαρακτηριστικά:
Mass & Dimension
8.5g, 17 x 18 x 28.5mm (WxHxD)
0.3 x 0.7mil Elliptical
Cantilever
⌀0.5mm Treated Aluminum Pipe
Coils
High-Purity Copper
Internal Impedance
28Ω
Load Impedance
>100Ω
Frequency Response
12Hz – 40kHz
Output
0.5mV
Channel Separation
30dB @ 1kHz
Channel Balance
<0.5dB @ 1kHz
Compliance
12×10-6cm/dyn @ 100Hz
Capacitance
100pF – 200pF
Vertical Tracking Angle
20°
Tracking Force Range
1.8g – 2.2g
Recommended Tracking Force
2.0g
Replacement Stylus Unit
Re-Tip Exchange (See Dealer)
| MPN | 8056684713622 |
|---|---|
| Cartridge Type: | MC |
| Output voltage at 1000 Hz, 5cm/sec | 2.5mV |
| Tracking force, recommended: | 2.0g |
| Tracking force range: | 1.8g – 2.2g |
| Recommended load resistance: | 47kΩ |
| Recommended load capacitance: | 100pF – 200pF |
| Frequency range at - 3dB: | 12Hz – 40kHz |
