Χαρακτηριστικά:
Cartridge Type: Moving Coil
Stylus: 0.3 x 0.7 micron Elliptical
Cantilever Material: coated aluminum pipe
Wire Material: pure copper
Internal Impedance: 135 Ohms
Load Impedance: 47kΩ
Frequency Response: 12Hz - 40kHz
Output Voltage: 2.5mV
Channel Separation: 30dB @ 1kHz
Channel Balance: <0.5dB @ 1kHz
Compliance: 12x10-6 cm/dyn @ 100Hz
Recommended load capacitance: 100pF - 200pF
Vertical tracking angle: 20°
Tracking Force: 1.8g - 2.2g
Recommended Force: 2.0g
Cartridge Weight: 8.5g
| MPN | 8056684713493 |
|---|---|
| Cartridge Type: | MC |
| Output voltage at 1000 Hz, 5cm/sec | 2.5mV |
| Tracking force, recommended: | 2.0g |
| Tracking force range: | 1.8g – 2.2g |
| Recommended load resistance: | 47kΩ |
| Recommended load capacitance: | 100pF – 200pF |
| Frequency range at - 3dB: | 12Hz – 40kHz |
