Tannoy TURNBERRY GR-OW

Brand

Tannoy Tannoy
SKU
0304-AAU
8.199,00 €

Ηχεία δαπέδου 2 δρόμων με ομοκεντρικό μεγάφωνο 10"

Σημείωση:
Διαθέσιμο προς ακρόαση

Calculating...

Οι τιμές των δόσεων είναι ενδεικτικές! Οι πραγματικές θα εμφανιστούν κατά την πληρωμή με πιστωτική κάρτα!.

Ηχεία δαπέδου 2 δρόμων με ομοκεντρικό μεγάφωνο 10"

2-Way Floorstanding 10" Dual Concentric HiFi Loudspeaker (Oiled Walnut)


Conveying all the power and musical articulation of the new Gold Reference Dual Concentric driver yet housed in a more compact 100 litre cabinet, Turnberry GR brings Prestige performance to smaller rooms. The 10in Gold Reference Dual, unique to the Turnberry GR, uses a new paper pulp cone material with HE twin roll fabric surround and 1.3in aluminium alloy dome tweeter with Tulip WaveGuide. Distributed Port loading ensure prodigiously deep LF response and dynamic scale that belies the Turnberry GR’s dimensions.

The hand-crafted plywood cabinet, finished in oiled real wood veneers and machined trim, is extensively braced to ensure low coloration and greater control. The easy to drive load and very high efficiency afford a wide range of partnering amplification from single ended triode to high power solid state designs. Classic looks, contemporary materials and the power of the Gold Reference Dual ensure Turnberry GR is as aesthetically pleasing as it is musically engaging.


Product Features
  • 2 way floorstanding loudspeaker for medium to large sized rooms

  • Dual Concentric driver technology provides class-leading coherence and point-source imaging

  • 10" highly efficient driver with 93 dB/Watt sensitivity and 400 Watt peak power handling deliver breath-taking dynamics and realism

  • Tulip Waveguide with 33mm aluminium-magnesium dome enhances the point source symmetrical dispersion properties, providing exceptional high frequency clarity and articulation

  • Low frequency paper pulp cone with twin roll fabric surround provide natural sounding midrange and bass transient performance

  • Handcrafted oiled walnut veneered cabinet with walnut inlays provides a unique and timeless piece of furniture

  • capacitors, low loss laminated core inductors and close tolerance wirewound resistors delivering a more natural and cohesive sound

  • Custom gold plated bi-wireable binding posts to improve signal transmission and integrity

  • Fifth binding post provides grounding to reduce radio frequency interference and improve midrange clarity

  • High density particle board cabinet provides extreme rigidity to control low frequency performance

  • Distributed Port system gives powerful and extended low frequency performance

  • Extensive bracing incorporating DMT (Differential Materials Technology) to couple drivers to cabinets

  • Precision machined gold anodised aluminium adjustment panel metal trim complements the aesthetic of the real wood cabinet

  • Specially formulated Prestige wood wax provided to keep cabinet in pristine condition

  • Tannoy - around 100 years of British sound heritage and innovation



Technical Specifications


System

Frequency response 1 34 Hz - 44 kHz (-6 dB)
Recommended amplifier power 20 - 200 W RMS
Power handling (IEC) 100 W continuous, 400 W peak
Nominal dispersion 90 degrees conical
Sensitivity 2 93 dB (1 W @ 1 m)
Impedance 8 Ω
Maximum SPL 2 113 dB continuous, 119 dB peak


Components

Low frequency dual concentric 254 mm (10") with paper pulp cone with twin roll impregnated
fabric surround, 52 mm (2") edge wound voice coil
High frequency dual concentric 33 mm (1.3") aluminium/magnesium alloy dome with edge
wound voice coil


Crossover

Frequency 1.3 kHz
Type Bi-wired, hard-wired passive, low loss 2nd order low pass,
2nd order high pass
Adjustment ±3 dB over 1.3 kHz to 44 kHz shelving


Enclosure

Type Dual distributed port
Connectors 5 x 4 mm 24 ct Tannoy customized binding posts
Dimensions (HWD) 950 x 456 x 336 mm (37.4 x 18.0 x 13.2")
Net weight 36.5 kg (80.3 lbs)
Construction 19 mm (3/4") MDF with plywood internal bracing, heavily damped
Finish Walnut veneer and high acoustic transparency nylon grill cover



Accessory pack (included)
Bi-wire bridge connectors
Prestige wood wax
Carpet protectors
Adjustable feet
Welcome pack documentation

Χαρακτηριστικά
Σημείωση:Διαθέσιμο προς ακρόαση
Δρόμοι2
Ευαισθησία:93
Αντίσταση:8
Απόκριση συχνότητας:34 Hz - 44 kHz (-6 dB)
