THORENS MM-008
Brand
THORENSCalculating...
Προενισχυτής phono
Compatiblity MM/MC cartridge (switchable)
RIAA-accuracy +/- 0,3 dB (20 Hz - 20 kHz)
Gain 40 dB (MM), 60 bB (MC)
Input Capacity 0, 100, 220 pF; switchable
Input Impedance MM 47 k Ohm + 220 pF fix
Input Impedance MC 47 k Ohm + 1 nF (load plugs to switch values)
Sensivity MM 3,29 mV RMS at -10 dBV output (316 mV RMS)
Sensivity MC 0,325 mV RMS at -10 dBV output (316 mV RMS)
Max. Output voltage 482 mV RMS at 5 mV RMS input (1 kHz)
Output impedance 47 Ohm
THD+N <0,013% (MM) / <0,055% (MC)
Frequency response flat 20 Hz - 20 kHz +/- 0,3 dB
Frequency responce -3 dB 10 Hz - 50 kHz
Signal to noise >86dB(MM)/>72dB(MC)
Crosstalk >= 40 dB
Input RCA MM, RCA MC, RCA load plugs
Output RCA
Power supply external 24VDC
Power consumption 3,4 W / 15 mA
Dimensions 150 x 50 x 117 mm (W x H x D)
Finish silver
Είσοδος: | MM/MC |
---|
