Tri-Plannar U12 MKVII
Calculating...
U-12
The new U-12 provides a significant 27% angular error reduction over smaller tonearms. See all the new enhancements below.
Features
• Carbon fiber wand with coaxial damping NEW
• 12" (308.80mm) effective length NEW
• Hand-polished components – rounded for resonance control NEW
• Larger silicone-fluid trough NEW
• Tonearm rest integrated with damping trough for resonance reduction NEW
• Pure silver internal tonearm wiring NEW
• Avionic bearings
• Damped head-shell
• Clamping yoke design that firmly couples the arm-tube to the bearing tube
• Bearings with hand-crafted, hardened and polished needle cones
• Bearings at record height
• Progressive anti-skating design
• Sophisticated system of decoupled conterweights
• Available in black or silver
Specifications
• Type: Gimbal avionic bearings
• Effective length: 308.80mm
• Pivot-to-spindle distance: 295.6mm
• Overhang: 13.2mm
• Offset angle: 17.6°
• Effective mass: 15g
• Bearing offset angle: 17.6°
Mk. VII
The unique dual-pivot design of this precision tonearm provides unrivaled tracking, transparency, and resolution.
The arm creates a musical sound stage unmatched by any other. It has been described as powerful and dynamic, solid yet expressive, delicate and tactile. The outstanding quality of this arm, commented on time and again, is that it is invisible, lacking the colorations that plague so many of our competitors.
Features
• Black or silver finish
• Damped headshell
• Annealed-aluminum coaxial damped armtube
• Clamping yoke design that firmly couples the headshell tube
to the bearing tube, making for a single unit yet allowing azimuth
rotation of the headshell
• Silicone-fluid trough tonearm damping
• Bearings featuring hand-crafted, hardened and polished needle cones
• Progressive anti-skating design
• Sophisticated system of decoupled counterweights, allowing proper stylus force for any cartridge without altering effective mass
• Easy 3-screw installation, with no large VTA hole
Specifications
• Type: gimbal-bearing tonearm
• Effective length: 250mm
• Pivot-to-spindle distance: 233.5mm
• Overhang: 16.5mm
• Offset angle: 22°
• Effective mass: 11g
• Bearing offset: 22°
